Oil-filled single-phase overhead transformers designed and produced by Chuanli are normally used for stepping utility distribution voltages (ranging from 2400 to 34500 volts) down to lower utilization voltages.
Overview
Oil-filled single-phase overhead transformers designed and produced by Chuanli are normally used for stepping utility distribution voltages (ranging from 2400 to 34500 volts) down to lower utilization voltages. Although some are used for stepping down to commercial and industrial voltages such as 277, 240/480, 2400 and 4800, most are used for stepping down to the single-phase voltage of 120/240.
These transformers are also used for small substations, miscellaneous applications and can serve to step up voltages.
The transformer type describes the basic protective devices which are included as an integral part of the transformer package. Table I defines each type as a function of the protective device(s) included. These protective devices and their functions are described later in this section
| Type | CSP | CP | SP | S |
| Protective Devices | ||||
| High Voltage Surge Arrester | Yes | No | Yes | No |
| Low Voltage Circuit Breaker | Yes | Yes | No | No |
| High Voltage Protective Link | Yes | Yes | Yes | No |
Type CSP, 5kV and Below, 10-100 kVA
Class A: Two fully insulated high voltage bushings, two arresters, two protective links, and external breaker handle. Suitable for application on either wye or delta distribution systems. Single-position pole mounting in accordance with latest ANSI standards.
Class B-1: Two fully insulated high voltage bushings, one arrester, two protective links and external breaker handle. Normally applied on solidly grounded systems.
Class B-2: Not Available.
Class B-3: Nol Available.
Type CSP, Above SKV, 10-100 kVA
Class A: Two fully insulated high voltage bushings, two arresters, two protective links and external breaker handle suitable for application on either wye or delta distribution systems. Single-position pole mounting in accordance with latest ANSI standards
Class B-1: Two fully insulated high voltage bushings, one arrester, two protective links and external breaker handle. Normally applied on solidly grounded systems.
Class B-2: One fully insulated high voltage bushing, one arrester, one protective link and external breaker handle suitable only for application on solidly grounded distribution systems.
Single-position pole mounting in accordance with latest ANSI standards
Class B-3: Same as Class 8-2 except with two-position mounting.
Type S. 5kV and Below, 10-500 kVA
Class A: Two fully insulated high voltage bushings, suitable for application on either wye or delta distribution systems. Singleposition pole mounting in accordance with latest ANSI standards.
Class B-1: Not Available
Class B-2: Not Available
Class B-3: Not Available
Type CSP, Above SKV, 10-100 kVA
Class A: Two fully insulated high voltage bushings, two arresters, two protective links and external breaker handle suitable for application on either wye or delta distribution systems. Single-position pole mounting in accordance with latest ANSI standards
Class B-1: Two fully insulated high voltage bushings, one arrester, two protective links and external breaker handle. Normally applied on solidly grounded systems.
Class B-2: One fully insulated high voltage bushing, one arrester, one protective link and external breaker handle suitable only for application on solidly grounded distribution systems.
Single-position pole mounting in accordance with latest ANSI standards
Class B-3: Same as Class 8-2 except with two-position mounting.
Single-Phase Overhead Conventional Transformer
Product Scope:
kVA: 5-167
Primary Voltage: 2400-19,920 V
Secondary Voltage: 120-600 V
Tachnical Data for Single-phase Overhead Conventional
Distributation Transformer
| Rated Power (KVA) | High Voltage (V) | Low Voltage (V) | Loss(W) | Dimension(mm) | Weight(kg) | ||||
| No-load Loss(W) | On-load Loss(W) | W | D | H | Oil Weight | Total Weight | |||
| 5 | 34500/ 19920 13800/ 7957 13200/ 7620 12470/ 7200 or others | 120-240 240-480 347 600 | 19 | 75 | 465 | 485 | 855 | 15 | 92 |
| 10 | 36 | 120 | 500 | 525 | 885 | 22 | 150 | ||
| 15 | 50 | 195 | 520 | 565 | 905 | 30 | 210 | ||
| 25 | 80 | 290 | 560 | 590 | 935 | 45 | 258 | ||
| 37.5 | 105 | 360 | 610 | 625 | 935 | 50 | 340 | ||
| 50 | 135 | 500 | 635 | 675 | 1035 | 62 | 395 | ||
| 75 | 190 | 650 | 745 | 840 | 1035 | 88 | 480 | ||
| 100 | 210 | 850 | 770 | 965 | 1135 | 94 | 530 | ||
| 167 | 350 | 1410 | 795 | 890 | 1335 | 138 | 680 | ||
Note: The above data is only subject to our standard design, special requirement can be customized
Single-Phase Overhead Completely Self Protected (CSP) Transformer
Product Scope:
kVA: 5-75
Primary Voltage: 2400-19,920V
Secondary Voltage: 120-600V
Tachnical Data for Single-phase Overhead Completely Self Protected (CSP)
Distributation Transformer
| Rated Power (KVA) | High Voltage (V) | Low Voltage (V) | Loss(W) | Dimension(mm) | Weight(kg) | ||||
| No-load Loss(W) | On-load Loss(W) | W | D | H | Oil Weight | Total Weight | |||
| 5 | 34500/ 19920 13800/ 7957 13200/ 7620 12470/ 7200 or others | 120-240 240-480 347 600 | 35 | 75 | 400 | 530 | 960 | 30 | 115 |
| 10 | 50 | 120 | 430 | 530 | 980 | 45 | 150 | ||
| 15 | 65 | 195 | 480 | 580 | 1000 | 55 | 205 | ||
| 25 | 105 | 290 | 500 | 580 | 1030 | 66 | 245 | ||
| 37.5 | 140 | 360 | 560 | 640 | 1080 | 78 | 335 | ||
| 50 | 180 | 500 | 560 | 640 | 1130 | 85 | 370 | ||
| 75 | 250 | 650 | 780 | 800 | 1170 | 138 | 505 | ||
Note: The above data is only subject to our standard design, special requirement can be customized
